    DDR-1B - 2 Tools Control Unit for Robot

    DDR-1B
    2 Tools Control Unit for Robot

    DISCONTINUED
    DDR-1B - 2 Tools Control Unit for Robot
    The DDR is a DD control unit that suits perfectly any robotic production system.

    Tools are connected via converter to guarantee the intelligent sleep and hibernation modes. No stand is required in this case.

    The DDR features a USB connector to communicate with the PC and a RS-232 output with a protocol for robots.

    It also incorporates the JBC exclusive heating system and a menu with over 20 parameters.

    This control unit works simultaneously with 1-2 tools and hundreds of JBC cartridges.


    Don’t believe us...
    TRY IT!
    REFERENCE
    DDR-1B
    PRODUCT COMPOSITION
    SPECIFICATIONS
    Net Weight3.6 kg (7.8 lb)
    Size145x120x225 mm
    Voltage(AC)120V
    Input Fuse4A
    Output Peak Power150W / 23.5V
    Temperature selection90-450 ºC / 190-840 ºF
    Tip to ground resistance<2 ohms
    Ambient operating temp.10-40 ºC / 50-104 ºF
    ESD Safe
    USB interface station-PC
    Package weight3.9 kg (8.6 lb)
    Package dimensions280x205x210 mm
